PIPEDATA-PRO

DATA SUMMARY


PARAMETERS

Size Range

1/4" to 48"

ASME Class

150#, 300#, 400, 600, 900, 1500, 2500

Pipe Schedules

5, 5s, 10, 10s, 20, 30, 40, 40s, 60, 80s, XS, 80, 100, 120, 140, 160, XXS

Rating

800, 2000, 3000, 6000

DIN Class (PN)

6. 10, 16, 25, 40, 64, 100, 160

BS 10 Table

A, D, E, F, H, J, K, R, S, T

API PSI

2000, 3000, 5000, 10000, 15000, 20000

Face Type

RF, RTJ, BW, SW, THD

Materials

Carbon Stl and Low Alloy Stl to 5Cr Stl
Stainless Stl 12Cr
Stainless Stl 'L' Grade

Insulation Thickness

25, 40, 50, 65, 75, 100, 150, 200.
(1", 1 1/2", 2", 2 1/2", 3", 4", 6", 8")


FLANGES


ASME B16.5 Flanges

WeldNeck Flange
Slip On Flange
Blind Flange
Threaded Flange
SocketWelded FlangeLapped Flange
Long Welding Neck Flange

ASME B16.47 Series A Flanges

WeldNeck Flange
Blind Flange

ASME B16.47 Series B Flanges

WeldNeck Flange
Blind Flange

Din Flanges

Blind Flange
Threaded Flange
Flat Flange
Weldneck Flange
Lapped Flange

API Type 6B Flanges

API Type 6B Weldneck
API Type 6B Threaded Flange
API Type 6B Blind

API Type 6BX Flanges

API Type 6BX WeldNeck Flange
API Type 6BX Blind and Test Flange

BS10 Flanges

BS 10 Flanges

Hub and Clamp

Hub-Clamp Pipe Connector

Orifice Flanges

Orifice Flange - WeldNeck
Orifice Flange - Slip On
Orifice Flange - Threaded

Compact Flanges

Standard
Swivel
Blind

Reducing Flanges

Threaded
Slip-On

VALVES

Flanged Valves

Flanged Gate Valve
Flanged Globe Valve
Flanged Ball Valve
Flanged Control Valve
Flanged Swing Check Valve
Flanged Wafer Check Valve
Wafer type Butterfly Valves
Lug type Butterfly Valves
Relief Valves for Layout

Buttwelded Valves

ButtWelded Gate Valve
ButtWelded Globe Valve
ButtWelded Ball Valve
ButtWelded Swing Check Valve

Threaded Valves

Threaded Gate Valve
Threaded Globe Valve
Threaded Horizontal Check Valve
Threaded Vertical Check Valve

Socketwelded Valves

SocketWelded Gate Valve
SocketWelded Globe Valve
SocketWelded Horizontal Check Valve
SocketWelded Vertical Check Valve

BLINDS AND SPACERS
Spectacle Blind
Line Spade and Spacer
RTJ Male Type Reversible Spade
RTJ Male Type Line Spade

WELDED BRANCHES


Olets

ButtWelded Olets
Threaded Olets
SocketWelded Olets
Weldoflange
Elbowflange
Latroflange
Nipoflange

Pipets

ButtWelded Pipets
Threaded Pipets
SocketWelded Pipets
Flanged Pipets

GASKETS
Flat C.A.F. ANSI
Flat C.A.F MSS
Flat C.A.F API 605
Spiral wound ANSI
Spiral wound ASME B16.47 Series A
Spiral wound ASME B16.47 Series B
RTJ soft iron ring type R
RTJ soft iron ring type RX
RTJ soft iron ring type BX

PIPE FITTINGS
Butt Welded
Threaded
Socket Welded
ANSI Composite Dimensions

PIPE
ANSI Pipe

NUTS
ISO Nuts
UNC Nuts

DESIGN AIDS


Pipe Flexibility

Pipe Leg
Pipe Loop

Safe spans

Safe rack spans
General safe spans

Safe Spacing

Safe Pipe Spacing
Safe Pipe Spacing with Insulation
Safe Flanged Pipe Spacing
Safe Flanged Pipe Spacing With Insulation
