Version 15.0.10, April 2025

Version 15.0.09, January 2025

  • ASME B16.5 Pressure-Temperature Rating calculator added
  • Safe Gap, select list added
  • The retain active settings feature has been extended across more components.
  • Improvements at lapped flange and stub end.
  • Pipedata-Pro 15.0 is now the primary release of Pipedata-Pro and receives intermediate upgrades at no additional cost.
  • Pipedata-Pro 14 series users can upgrade to Pipedata-Pro 15 series at no cost until 30 June 2025.

Version 14.1.10, November 2024

    Download Version 14.1.10
  • Stainless Steel Pipe size range adjustments to match ASME B36.19-2022, affects 1/8", 1/4" and 3/8" Sch 5s pipe and 30" 40s and 30" 80s pipe.
  • 'Check for Updates' icon revised.

Version 14.1.09, October 2024

  • Imperial dimensions have been revised at Class 300# Witch-Hat Type Strainer.

Version 14.1.08, February 2024

  • ASME B36.10M-2018 Pipe dimensions are now shown to 3 decimal places as specified in the ASME specification.
  • ASME B16.36-2020 Orifice Flanges bolt hole quantity and diameter now show properly on drawing.
  • ASME B16.10-2017 Flanged Ball Valves, where the weight for large valves isn't available it is now shown as 'N/A' and not '0'.
  • Center to end dimensions adjusted at 3000lb Threaded Street Elbow.

Version 14.1.07, July 2023

  • ASME ball valve weights are now based on two and three piece bolted valves previously they were based on fully welded style valves. This has increased the displayed weight however the bolted valves are considered to be nearer to the prevailing norm.

Version 14.1.06, March 2023

  • Bug fix at small strainers

Version 14.1.05, October 2022

  • Socket-Welding and Threaded Valve weights, were reviewed and adjusted.

Version 14.1.04, April 2022

  • New Pipedata-Pro logo
  • Icons added to dropdown selector lists
  • Safe Span display updated
  • Butt-Welding gate valve display updated
  • Header toolbar select items made more consistent
  • Settings now available from the footer toolbar

Version 14.0.13, January 2022

  • Bug fix at B16.5 Lapped Flange
  • Ease of use Improvements at Din Flanges and Strainers
  • New style 'Check for Update' icon

Version 14.0.12, December 2021

  • New style version number
  • Active Size, Class, Face, and Schedule, etc. are now where possible retained within each component group
  • Ease of use improvement at Buttwelding Cap
  • B16.5 Straight Hub Welding Flange: RTJ option added and more dimensional and weight information added
  • Tweak for Windows 11
  • New style installer

Version 14.0.00.11, August 2021

  • Orifice Flanges: ASME B16.36-2020 (Replaced ASME B16.36-2015)
  • Pipe Flanges: ASME B16.5-2020 (Replaced ASME B16.5-2017)
  • Line Blanks: ASME B16.48-2020 (Replaced ASME B16.48-2015)
  • Small adjustments to weights and bolt lengths at B16.47 Series ‘A’ 150# flanges

Version 14.0.00.8, November 2020

  • Optimization for upcoming Windows 10 Releases
  • Small corrections and bug fixes

Version 14.0.00.7, August 2020

  • Security system simplified and other improvements

Version 14.0.00.6, August 2020

  • Auto Update removed as generally not prefered by users.
  • Adjustment to weights at (DIN) EN 1092-1 Flanges.
  • Small adjustments to lever and gear operator dimensions at flanged ball valves

Version 14.0.00.5, July 2020

  • Globe, Ball and Swing Checks to dimensional spec ASME B16.10. The weights of these valves are now based entirely on Schlumberger/Cameron valves resulting in small adjustments to the published weights.

Version 14.0.00.4, May 2020

  • New single license key activation
  • New style 'About form', with more information.

Version 12.2.09.35, April 2020

  • Download Version 12.2.09.35
  • B16.11 threaded fittings, weights reviewed and adjusted
  • BS 10 Table ‘D’ Flanges, bolt hole diameters now specified as bolt size plus 1/8” (3mm) throughout
  • At US Customary Units, ½” 150# B16.5 flange, cumulative overall length corrected

Version 12.2.09.32, April 2019

  • 1.5 inch NPS pipe fraction inch OD corrected
  • DIN Flange (EN1092-1) DN65 PN16 hole qty option revised from 4 to 8
  • DIN DN700 PN10 thickness now 38mm at blind flange
  • Imperial database re-attached at Socket-Welding Valves

Version 12.2.09.25, July 2019

  • Bug fix, Buttwelding Cap with imperial settings
  • Bug fix, 45deg Threaded Elbow, size wasn’t updating in top menu
  • Socket-Welding Half Coupling Wall Thickness amended
  • Metallic Gaskets Specification text changed from B16.21 to B16.20
  • Specification year numbers updated
  • Main icons reverted

Version 12.2.09.24, April 2019

  • Menu at safe spans and flexibility made consistent
  • Printing issue on some device/OS combinations fixed
  • Gear operation now uniform at flanged and butt welding end - gate, globe and ball valves, a gear operator is provided at these sizes and above:
    ASME Class 150# = 14" (DN350)
    ASME Class 300# = 10" (DN250)
    ASME Class 600# = 10" (DN250)
    ASME Class 900# = 10" (DN250)
    ASME Class 1500# = 8" (DN200)
    ASME Class 2500# = 6" (DN150)
    Where gear operation is shown its weight is included in the displayed valve weight.

Version 12.2.08.09, March 2018

  • Range extended at Swage and Pipe Nipples

Version 12.2.07.67, January 2018

  • Process Area Spans added
  • Pipe by Wall Thickness, matching Schedules added

Version 12.2.06.32, November 2017

  • Stud-bolt lengths now shown at 'Line Blanks and Spacers' included for flat face, raised face, male and female ring type joints. For figure 8 line blank and paddle blanks and spacers.
  • Dimension annotation at Din and British standard flanges revised to be same format as for ASME flanges for consistency

Version 12.2.00.00, July 2017

  • Quicker installer with auto-uninstall/install
  • Retains license and settings

Version 12.1, April 2017

  • Forward/Back Navigation between previously selected components
  • New logo and upgraded Icons
  • Component search feature
  • 'Quick Print' facility

Version 12.0, January 2016,

  • New Look and Feel
  • Simple Menu Structure
  • Structural steel section dropped
  • Optimizations, tweaks and debugs

Version 11.0, January 2016

  • Download Version 11.0
  • ASME Pipe Size Range Extended , now to 80" by wall thickness
  • Optimizations, tweaks and debugs

Version 10.0, April 2015

  • Download Version 10.0
  • MS Windows 10 compatibility enabled
  • B16.5 - Pipe Flanges Validate to ASME B16.5 2013
  • B16.9 - Butt welded Fittings Validated to ASME B16.9 2012
  • B16.10 - Face-to-Face of Valves Validated to ASME B16.10 2009
  • B16.11 - Forged Fittings Socket-Welding and Threaded Validated to ASME 2011
  • B16.20 - Metallic Gaskets for Pipe Flanges Validated to ASME B16.20 2012
  • B16.21 - Non-metallic Flat Gaskets for Pipe Flanges Validated to ASME B16.21 2011
  • B16.36 - Orifice Flanges Validated to ASME B16.36 2009
  • B16.47 - Large Diameter Steel Flanges Validated to ASME B16.47 2011
  • B36.10M - Carbon Steel Pipe Validated to ASME B16.36.10M 2004/R2010
  • B36.19M - Stainless Steel Pipe Validated to ASME B16.36.19M 2004/R2010

Version 9.3, September 2014

  • Download Version 9.3
  • Corrosion and Insulation Combo's now include imperial settings
  • Stud bolt weights validated to latest vendor information
  • Metric pipe sizes at strainers functionality added

Version 9.2, August 2014

  • Enhanced Safe Span Calculator.
  • Data for socketwelded and threaded small bore ball valves now included
  • Stud bolt lengths at large bore ASME B16.7 flanges now rounded to nearest quarter inch.
  • General tweaks and debugs.

Version 9.1, July 2004

  • Corrosion Allowance and Manufacturing Tolerances now customisable.
  • On calculating the wall thickness the nearest schedule is found and displayed.

Version 9.0, March 2014

  • Legacy dimensions added.
  • Strainers added.
  • General updates.

Version 8.5, July 2013

Version 8.4, February 2013

  • B16.20 BX RTJs range extended from BX-160 to BX-303.
  • Dimensional data added for RTJ at B16.47 Series 'A' Flanges.
  • Reducing Flanges validated to latest ASME standard.
  • Orifice Flanges validated to latest ASME standard.
  • B16-20/21 Gaskets validated to latest ASME standard.

Version 8.3, August 2012

  • Microsoft® Windows 8 Validated and Certified.
  • When switching between forms the active properties are now retained.

Version 8.2, July 2012

  • Large Diameter Steel Flanges have been validated to the latest ASME specifications.
  • Valve Weights aligned with the latest manufactured weights.
  • Butt-Welded Fittings have been validated to the latest ASME specifications.
  • No Splash Screen - Quicker Opening.
  • Bore and Pipe Wall Thickness added to ASME B16.5 flanges.

Version 8.1, March 2011

  • General intermediate update, - numerous ease of use improvements.
  • New network license system, - works seamlessly under Vista and Windows 7 as well as XP and earlier.
  • Always on top feature default setting is now set to ‘off’.
  • PipeData-PRO Travelman USB enabled.

Version 8.0, February 2009

  • Fully validated to latest issue of ANSI B16.5.
  • Easy to use pipe diameter calculator.
  • Easy to use pipe wall thickness calculator.
  • Easy to use flange pressure/temperature calculator.

Version 7.5, June 2010

  • Download Version 7.5
  • Better printing.
  • Feeback, Adweights and Corportate Partner links added.
  • Converter now points online (if you are offline it reverts to embedded Converter).
  • The size ranges at 'Pipe Spacing' have been increased.

Version 7.3, June 2007

  • Always On Top feature added.
  • Schedule thickness added at ASME B16.5 flanges.
  • ASME B16.48 blinds and spacers added.
  • The size range of ASME B16.47 flanges size range increased.
  • Ball valve weights are now calculated within the software.
  • US Gallons added to Converter.
  • At 'customise insulation thicknesses' the defaults are now restorable.

Version 7.2, February 2005

  • Full class range of ASME B16.47 Series 'B' flanges added and Series 'B' blind flange added.
  • Relief Valve nominal sizes and weights have been added for layout and weight.
  • UK parallel flange, rolled steel channels added.
  • The latest ANSI dimensions for swing check flanged valves face to face.
  • Advice on when 900#/1500# flange listings are the same.
  • MSS and API 605 gaskets renamed to ASME B16.47 Series A and B respectively.
  • Data folder structure re-organised and now in dxf and csv format.

Version 7.1, June 2004

  • ANSI Reducing Flanges dimensional data and weight added.
  • - and when to use a drilled or tapped blind instead.
  • Weldoflange, Elboflange, Latroflange and Nipoflange dimensional data added.
  • ANSI Compact flanges, dimensional data and weight added.
  • Custom insulation thicknesses at safe gaps and safe spans.
  • Fahrenheit option at pipe flexibility calculations.
  • Advice on specifying Class 800# and 1500# SW/THD valves.




Version 15.0.0 incorporates Flange Pressure-Temperature Rating calculator.


Version 14.1.10 Stainless Steel Pipe size range adjustments to match ASME B36.19-2022


Version 14.1.09 Witch-Hat Type Strainer Revision


Auto Gear Operator selection


Extended range at Swage and Pipe Nipples


Bolt Lengths at Line Blanks and Spacers
